XAR400 steel plate

XAR400(1.8714) wear-resistant plate is a special structural steel with high wear resistance produced by ThyssenKrupp Steel plant in Germany. Generally, the higher the hardness, the higher the wear resistance. The average hardness of this wear-resistant special mechanism steel is 400HB, and after quenching or quenching and tempering, it has a good martensitic-bainite microstructure.

Whatsapp: +8615110142690

E-mail: tj001@tjbgsteel.com

RELATED PRODUCTS

ONLINE MESSAGE

Keywords:

Wear Plate

Classification :

Wear Plate

PRODUCT DETAILS

XAR400 wear-resistant plate main application: Construction machinery: cement pusher tooth plate, concrete mixing building, mixer lining plate, dust collector lining plate, brickmaking machine mold plate Engineering machinery: loader, bulldozer, excavator bucket plate, side edge plate, bucket bottom plate, blade, rotary drilling rig drill rod

XAR400 delivery condition: Quenched or quenched + tempered

Hardness (room temperature):370-430 HBW

The conventional stock thickness of XAR400 wear-resistant steel plate is 4~100mm, and the conventional size is 2000*6000 or 2500*8000. Mechanical characteristics of XAR400 wear-resistant plate :(typical parameters of 15mm thick steel plate)*)1MPa=1N/mm carbon equivalent CET(%)CET=C+(Mn+Mo)/10+(Cr+Cu)/20+Ni/40 CE(%)CE=C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15 0.48

Yield strength Rp0,2 MPa:1050
Tensile strength Rm MPa:1250
Elongation A5% :12
Impact strength ratio V20J:-40C
