ASTM A131 Grade A/B Marine Steel Plate

ASTM A131 marine steel plates can be used to manufacture hull structures for ocean-going, coastal and inland navigation vessels. Steel plates for shipbuilding are required to have certain strength, toughness, low temperature and corrosion resistance as well as good welding performance.

Whatsapp: +8615110142690

E-mail: tj001@tjbgsteel.com

RELATED PRODUCTS

ONLINE MESSAGE

Keywords:

Shipbuilding Steel Plate

Classification :

Shipbuilding Steel Plate

PRODUCT DETAILS

Brief introduction of marine steel plate

Name	Shipbuilding Steel Plate
Thickness	5mm-200mm
Width	1500mm-3000mm Customizable
Length	3000mm-12000mm Customizable
Material	AH32, DH32, EH32, FH32, AH36, DH36, EH36, FH36, AH40, DH40, EH40, FH40, CCSA, CCSB, CCSD
Classification Code	CCS, ABS, GL, BV, DNV, NK, LR, KR, RINA
Features	Waterproof, Non-Slip, Fireproof, Anti-Corrosion, Anti-Static
Characteristic	Excellent Tensile Strength, Good Clutch And Welding Performance, High Corrosion Resistance, Sufficient Impact Toughness, Good Plasticity, Good Heat Treatment Control
Application	Manufacture Ocean-Going, Coastal And Inland Waterway Navigation Vessels, Fishing Vessels And Marine Engineering Structures
Delivery Status	Normalizing, Tempering, First Test, Second Test, Third Test

Marine steel plate refers to structural steel used in ship building. It is considered a marine grade and must be able to resist corrosive effects that are common in a water environment. To achieve this, special alloying elements are added to these grades in order to defend agaist corrosion.While most carbon steel is not suited for marine environments, there are several marine grade carbon steels that have been approved by the different societies for shipbuilding applications.

Structural steel for ship hulls is divided into strength classes according to its minimum yield strength: general strength structural steel and high strength structural steel. Maine steel plate refers to hot rolled steel plate produced in accordance with the requirements of the classication society for the construction of ship hull structures.

There are 9 main classification societies in worldwide.
A.B.S American Bureau of Shipping
B.V. Bureau Veritas
C.C.S. China Classification Society
D.N.V Det Norske Veritas
G.L. Germanischer Lloyd
K.R. Korean Register of Shipping
L.R. Lloyd’s Register of Shipping
N.K. Nippon Kaiji Kyokai
R.I.N.A Registro Italiano Navale

Grade AH32 steel is the impact force subjected to 0 ° C
Grade DH32 steel impact force at -20 ° C
Grade EH32 steel impact force at -40 ° C
Grade FH32 steel impact force at -60 ° C

Shot blasting service
Shot blasting is a method used to clean or polish steel when enhanced surface finishes are required. Shot blasting is used in almost every industry we serve. Especially in shipbuilding, rail,structural fabrication and more.

Specifications range
Thickness:2.5-120mm
Width:1000-3000mm
Length: As request

Chemical composition and mechanical properties

Steel grade	C	Si	Mn	P	S	Als
Grade AH32	≤0.18	≤0.50	0.9-1.6	≤0.035	≤0.035	≥0.015
Grade DH32	≤0.18	≤0.50	0.9-1.6	≤0.035	≤0.035	≥0.015
Grade EH32	≤0.18	≤0.50	0.9-1.6	≤0.035	≤0.035	≥0.015
Grade FH32	≤0.18	≤0.50	0.9-1.6	≤0.035	≤0.035	≥0.015
